- Product description
-
Characteristic
- 1.Whole series TÚv class0certification
Passed the newly issued Is08573-1:2010standard ( Certified by TÜV-SUD )
- 2.High efficiency air end
Adopting Japanese scroll compressor technology Compressor operation vibration value≤0.3mm/s
- 3.Automotive grade high efficiencyPM VSD motor
IE5 energy efficiency, IP67 protection class ,Starting current is only 5% of asynchronousmotor
- 4.All-in-one inverter High efficiency inverter drive technology
Highly efficient for different workingconditions and application scenarios
Energy-saving, environmentally-friendly, andcost-efficient- 5.Industry 4.0 loT Touch Screen
Digital Intelligent touch-screen control panel , Embedded Integrated loT Module
Malfunction alarm, one touch to control alloperating parameters- 6.One-stop solution for compressed air
Contains air vessel, module dryer, drain valve etc.
Occupying only 0.4m² footprint
Specification Parameters
Model
Power kW
Horse Power HP
Voltage V
Bar bar
Displacement L/min
Air vessel L
Dimension mm
C2AK/C2AH
1.5
2
220V/380V
8
140
25
880*870*950
10
120
C3AK/C3AH
2.2
3
220V/380V
8
240
25
880*870*950
10
200
C5AK/C5AH
3.7
5
220V/380V
8
410
70
980*870*1400
10
340
C7AK/C7AH
5.5
7
220V/380V
8
620
70
980*870*1400
10
540
C10AK/C10AH
7.5
10
220V/380V
8
820
70
980*870*1400
10
710
