DE Screw Air Compressor Oil-lubricated (air compressor+air vessel)

DE Screw Air Compressor Oil-lubricated (air compressor+air vessel)

WhatsApp:

86 13862059949

Product description

Product features:

Innovative Patent Technology D-Series Airend
- Features a completely redesigned airend rotor, reducing noise, increasing load capacity, and offering a highly integrated airend unit with a rust-free warranty.
High-Efficiency Oil-Air Separation System with Aerospace-Grade Aluminum Separation Tank
- Equipped with an advanced oil-air separation system that ensures ultra-fine separation, with the outlet oil content as low as 0.5 PPM, enhancing overall system efficiency.
Custom Heavy-Duty Inverter
- The inverter intelligently controls the system, automatically stopping when the set pressure is reached, reducing idle time and significantly lowering energy consumption and operational costs.
Oil-Cooled Motor (IP65 Protection)
- Features a high-efficiency IE4 permanent magnet motor, providing high starting torque and operating at low temperatures across all frequencies. It is rated IP65 for water and dust protection, with a maintenance-free, bearingless design, using 180°C high-temperature-resistant permanent magnet materials, F-class insulation, and vacuum-epoxy coil encapsulation technology.
Self-Developed Silencing Air Filter & External Oil Separator
- The high-performance air filter offers superior intake filtration and effective noise isolation, while the external oil separator and 304 stainless steel oil filter enable 100% self-maintenance, reducing operational and maintenance costs. An optional auto-drain and precision filter are also available for a nearly installation-free solution, ensuring up to 100% oil-free compressed air.

Specification Parameters

Model	Power (kW)	Horse Power (HP)	Voltage (V)	Pressure (bar)	Displacement( L/min)	Air vessel (L)	Dimension (mm)	Outlet Size
C3DE	2.7	3	220/380-50	8	300	100	1110565925	G1/2
				10	280
C5DE	3.7	5	220/380-50	8	400	100	1110565925
				10	380
				12.5	300
C7DE	5.5	7	220/380-50	8	650	200	13008001170
				10	520
				12.5	380
C10DE	7.5	10	220/380-50	8	980	200	13008001170
				10	780
				12.5	650
C15DE	11	15	380-50	8	1300	300	158011701400	G3/4
				10	1150
				12.5	1020
C20DE	15	20	380-50	8	1900	300	158011701400
				10	1510
				12.5	1280
