  • Product description

  •



    Characteristic

    • 1.Whole series TÚv class0certification

    Passed the newly issued Is08573-1:2010standard ( Certified by TÜV-SUD )

    • 2.High efficiency air end

    Adopting Japanese scroll compressor technology Compressor operation vibration value≤0.3mm/s

    • 3.Automotive grade high efficiencyPM VSD motor

    IE5 energy efficiency, IP67 protection class ,Starting current is only 5% of asynchronousmotor

    • 4.All-in-one inverter High efficiency inverter drive technology

    Highly efficient for different workingconditions and application scenarios
    Energy-saving, environmentally-friendly, andcost-efficient

    • 5.Industry 4.0 loT Touch Screen

    Digital Intelligent touch-screen control panel

    Embedded Integrated loT Module
    Malfunction alarm, one touch to control alloperating parameters

    Specification Parameters

    Model

    Power kW

    Horse Power HP

    Voltage V

    Bar bar

    Displacement L/min

    Air vessel L

    Dimension mm

    C2A

    1.5

    2

    220V/380V

    8

    140

    25

    640*870*950

    10

    120

    C3A

    2.2

    3

    220V/380V

    8

    240

    25

    640*870*950

    10

    200

    C5A

    3.7

    5

    220V/380V

    8

    410

    70

    740*870*1400

    10

    340

    C7A

    5.5

    7

    220V/380V

    8

    620

    70

    740*870*1400

    10

    540

    C10A

    7.5

    10

    220V/380V

    8

    820

    70

    740*870*1400

    10

    710
